In-Vehicle Computer with LGA 1200 for Intel 10th Gen CPU & W480E PCH, 2x LAN, 1x PCIe
| System | |
|---|---|
| Processor | Support 10th Gen Intel® CML S Processor (LGA 1200, 65W/35W TDP) Intel® Xeon® W-1290TE, 10 Cores, 20MB Cache, up to 4.5 GHz Intel® Xeon® W-1270TE, 8 Cores, 16MB Cache, up to 4.4 GHz Intel® Xeon® W-1250TE, 6 Cores, 12MB Cache, up to 3.8 GHz Intel® Core™ i9-10900E, 10 Cores, 20MB Cache, up to 4.7 GHz Intel® Core™ i9-10900TE, 10 Cores, 20MB Cache, up to 4.5 GHz Intel® Core™ i7-10700E, 8 Core, 16MB Cache, up to 4.5 GHz Intel® Core™ i7-10700TE, 8 Cores, 116MB cache, up to 4.4 GHz Intel® Core™ i5-10500T, 6 Cores, 12MB Cache, up to 4.2 GHz Intel® Core™ i5-10500TE, 6 Core, 12MB Cache, 3.7 GHz Intel® Core™ i3-10100T, 4 Cores, 6MB cache, up to 3.8 GHz Intel® Core™ i3-10100TE, 4 Cores, 9MB Cache, up to 3.6 GHz |
| System Chipset | Intel® W480E Chipset |
| LAN Chipset | GbE1: Intel I219 (Support Wake-on-LAN and PXE) GbE2: Intel I210 (Support Wake-on-LAN and PXE) |
| Audio Codec | Realtek ALC888S |
| System Memory | 2x 260-Pin DDR4 2666 /2933MHz SODIMM. Max. up to 64GB (ECC and Non-ECC) |
| Graphics | Intel® UHD Graphics 630 |
| BIOS | AMI 256Mbit SPI BIOS |
| Watchdog | Software Programmable Supports 1~255 sec. System Reset |
| TPM | TPM 2.0 |
| Display | |
|---|---|
| Display Port | 2x DisplayPort, support resolution 4096 x 2304, DP++ |
| DVI | 1x DVI-I, support resolution 1920 x 1200 |
| Multiple Display | Triple Display |
| VGA | Yes (by optional split cable) |
| Storage | |
|---|---|
| M.2 | 1x M.2 (E Key, PCIe x1, USB 2.0, 2230, Support CNVi) |
| SIM Socket | 2x External SIM socket (Mini PCIE attached) |
| SSD/HDD | 1x Internal 2.5" SATA/SSD HDD Bay (support H=9mm) 2x Removable 2.5" SATA HDD Bay (support H=7mm, Hot-swappable) Support RAID 0, 1, 5 |
| Expansion | |
|---|---|
| Mini PCIe - 2x Full-size Mini PCIe | |
| PCIe - 1x PCIe x16 (Model ACO-6000-CML-1E) | |
| PCI - 1x PCI (Model ACO-6000-CML-1I, Optional) | |
Expansion Modules connector (PoE optional) |
| Operating System | |
|---|---|
| Windows | Windows 10 |
| Linux | Linux kernel |
| I/O | |
|---|---|
| Audio | 1x Mic-in, 1x Line-out |
| CAN | 2x CAN 2.0 A/B 2-pin Internal header |
| COM | 2x RS-232/422/485 ; 6x RS-232/422/485 (internal) |
| DIO | 8 in / 8 out (Isolated) |
| LAN | 2x RJ45 |
| Universal I/O Bracket | 2x Universal I/O Bracket (By mini PCIe interface) |
| USB | 6x USB 3.2 Gen 2 (10 Gbps) 3x USB 3.2 Gen 1 (5 Gbps, 1x Internal) 2x USB 2.0 header (internal) |
| Others | 5x WiFi Antenna Holes 1x Power Switch, 1x AT/ATX Switch, 1x Remote Power On/Off 1x PC/Car Mode Switch, 1x Delay Time Switch 1x Removable CMOS Battery 4x 4-Pin Power Connector, 1x 4-PIN FAN Connector |
| Power | |
|---|---|
| Power Adapter | Optional AC/DC 24V/5A, 120W Optional AC/DC 24V/9.2A, 220W |
| Power Mode | AT, ATX |
| Power Ignition Sensing | Power Ignition Management |
| Power Supply Voltage | 9~48VDC 48~110VDC (Optional) |
| Power Connector | 5-pin Terminal Block 3-pin Terminal Block (48~110VDC, Optional) |
| Power Protection | OVP (Over Voltage Protection); OCP (Over Current Protection) Reverse Protection |
| Environment | |
|---|---|
| Operating Temperature | -25°C to 70°C (35W/65W CPU) |
| Storage Temperature | -30°C to 85°C |
| Relative Humidity | 10% to 95% (non-condensing) |
| Certification | CE, FCC Class A E-Mark, EMC Conformity with EN50155 & EN50121-3-2 |
| Vibration | With SSD: 3 Grms, 5 - 500 Hz, 0.5 hr/axis With HDD: 1 Grms, 5 - 500 Hz, 0.5 hr/axis |
| Shock | With SSD: 20G, half sine, 11ms |
| Physical | |
|---|---|
| Construction | 240 (W) x 261 (D) x 127.3 (H) mm |
| Weights | |
| Construction | Extruded Aluminum with Heavy Duty Metal |
| Mounting Options | Wall Mounting |
